JBD-DB24SA03 is a software BMS scheme specially designed for 8-24 strings of lithium battery packs.The product adopts architecture of front-end acquisition chip by Deve chip and MCU by Telink. The part of protection parameters can be flexibly adjusted through the upper computer according to customer needs. jiabaida DB24SA03 bms supports 7s-24s (NMC up to 20s) LiFePo4 and Li-ion lithium battery, 40a-80a continuous current is optional, comes with Bluetooth and an uart interface, suitable for electric motorcycles, electric tricycles and low-speed four-wheeled.
