Jiabaida BMS
JBD Normal bms 7S 8S 10S 12S 13S 14S 16S 15A~30A Lithium Battery PCB with Passive Balance
Couldn't load pickup availability
HP16SA Normal bms
- Model Number: JBD-HP16SA
- Place of Origin: Guangdong, China
- Supplier Type: Manufacturer
- Electricity: 30A
- Voltage: 24V/36V/48V/60V
- Product Name: BMS
- Brand Name: JBD
- Application: Electronic Products
- Usage: Lithium Battery Packs
- Package: Standard Package
- Testing: 100%testing
- Supply Ability: 300000 Piece/Pieces per Month
- Package Content : 1* BMS *Balance wires
Product Description
JBD-HP16SA
JBD-HP08S001 is the hardware BMS which designed for battery packs of the inverter, the electric bicycles and the electric motorcycles of batter packs by Dongguan City Jia Bai Da Electronic Technology Co., Ltd.It can be applied to lithium batteries with different chemical properties, such as lithium ion, Li-polymer. Lithium iron phosphate, etc. The protection board has strong loading capacity and the maximum continuous discharge current can reach 30A.
● 7-16 cell series protection
● Various protection functions for charging and discharging
● short circuit protection functional processes of hardware
● reserves the discharging control switch and the position of discharging temperature protection,
● Very low static current consumption
● Containing charging equalization function
● Discharge overcurrent, short circuit protection functional processes of hardware
Application
|
Battery series
|
Battery Rated Voltage
|
Battery series
|
Battery Rated Voltage
|
|
7
|
3.6V/3.7V(24V)
|
8
|
3.2V(24V)
|
|
10
|
3.6V/3.7V(36V)
|
12
|
3.2V(36V)
|
|
13
|
3.6V/3.7V(48V)
|
14
|
3.6V/3.7V(48V)
|
|
16
|
3.6V/3.7V(60V)/3.2V(48V)
|
||
